CDM6225 Cummins Ⅱ, Chinese HYD, W=2540mm
Excavator
CDM6225 Cummins Ⅱ, Chinese HYD, W=2540mm
112 kW/1950 rpmRated Power
21800 kgOperating Weight
3.1/5.3 km/hTravel Speed
5.9 LDisplacement
Overview
The Lonking CDM6225 Cummins Ⅱ, Chinese HYD, W=2540mm is a excavator built for dependable, efficient operation. Powered by a 6BTAA5.9-C150-II engine producing 112 kW/1950 rpm, with an operating weight of 21800 kg. Its robust drivetrain, precise hydraulics and operator-focused cab make it well suited to construction, mining, agriculture and industrial material-handling tasks.
Key Features
- 112 kW/1950 rpm engine output tuned for productive operation
- Ergonomic operator cab for comfort and visibility across long work shifts
- Supported by Lonking global genuine parts and after-sales service network
Technical Specifications
BASIC
| Operating weight | 21800 kg |
| Boom length | 5675 mm |
| Arm length | 2920 mm |
| Standard bucket | 1.1 m³ |
| Max.Travel speed | 3.1/5.3 km/h |
| Max.Swing speed | 13.5 rpm |
| Grade ability | 35(70%) ° |
| Ground pressure | 54.4 kPa |
| Max.Traction force | 218 kN |
ENGINE
| Engine model | 6BTAA5.9-C150-II |
| Rated power | 112 kW/1950 rpm |
| Max.Torque | 614/1500 Nm/rpm |
| Displacement | 5.9 L |
| Fuel tank | 303 L |
HYDRAULIC
| Max.Flow(total) | 280×2 L/min |
| Max.Working pressure | 35 MPa |
| Max.Pilot pressure | 4.0 MPa |
| Max.Arm digging force | 101 kN (ISO) |
| Max.Bucket digging force | 139 kN (ISO) |
| Hydraulic oil tank | 150/235 L |
CHASSIS
| Track width | 500 mm |
| Track shoes number | 49 each side |
| Carrier rollers number | 2 each side |
| Track rollers number | 8 each side |
ELECTRIC
| System voltage | 24 V |
| Battery capacity | 24V, 120Ah×2 |
