LG876HS Weichai Ⅲ+ZF Automatic Transmission
Wheel Loader
LG876HS Weichai Ⅲ+ZF Automatic Transmission
199kW/2200rpmRated Power
7000kgRated Payload
23500(24300)±300kgOperating Weight
5.2m³ (7.0m³ NGM)Bucket Capacity
Overview
The Lonking LG876HS Weichai Ⅲ+ZF Automatic Transmission is a wheel loader built for dependable, efficient operation. Powered by a high-efficiency engine producing 199kW/2200rpm, it handles a rated payload of 7000kg with an operating weight of 23500(24300)±300kg. Its robust drivetrain, precise hydraulics and operator-focused cab make it well suited to construction, mining, agriculture and industrial material-handling tasks.
Key Features
- 7000kg rated capacity provides the working power your jobsite demands
- Countershaft Powershift drivetrain for smooth, reliable power delivery
- High-performance hydraulic system operating at 18MPa
- Ergonomic operator cab for comfort and visibility across long work shifts
- Supported by Lonking global genuine parts and after-sales service network
Technical Specifications
BASIC
| Bucket Capacity | 5.2m³ (7.0m³ NGM) |
| Rated Payload | 7000kg |
| Operating Weight | 23500(24300)±300kg |
| Traction Force | 200±3kN |
| Breakout Force | 245±3kN |
| L×W×H | 9200(9430)×3400(3480)×3460mm |
ENGINE
| Maker/Model | WEICHAI/WP10G270E341 |
| Rated Power | 199kW/2200rpm |
| Maximum Torque | 1100N·m/1400-1600rpm |
| Bore x Stroke (mm) | 126×130mm |
| No. of Cylinders/Displacement | 6/9.726L |
| Air Cleaner | Three Stage Air Cleaner |
| Alternator | 70Amp |
| Battery | 2-24V/120Ah |
| Starting Motor | 24V/7.5kW |
DRIVE TRAIN
| Transmission Type | Countershaft Powershift |
| Shift Type | Automatic electric proportional shift |
| Pressure of Transmission | 1.2-1.5MPa |
| Torque Converter Type | Single-stage,Duo-turbine,4-element |
| Axles | Rigid (Front)&Oscillating (Rear) |
| Rear Axle Oscillation (°) | ±10 |
| Differential | Conventional |
| Main Reducer | Spiral Bevel,1-stage Reduction |
| Final Reducer | Planetary Reduction |
| Tire | 750/65R25★L-3TL |
| Travel Speed-Forward | 6.7/13.2/24.6/36 km/h |
| Travel Speed-Reverse | 7.1/13.9/24.9 km/h |
BRAKE SYSTEM
| Service Brake | Single-Line Air Push oil,Dry Brake |
| Setting Pressure | 0.70-0.78MPa |
| Parking Brake | Pneumatic Drum Brake |
| Emergency Brake | Pneumatic Drum Brake |
STEERING SYSTEM
| Type | Flow Amplification Steering |
| System Pressure | 18MPa |
| Cylinder Type | Double Acting |
| Steering Angle | ±35° |
HYDRAULIC SYSTEM
| Type | Constant Variable Double Pump Confluence |
| Pump | 232L/min-2200rpm |
| Control Valve | 2 Spool |
| System Pressure | 23MPa |
| Cycle Time (Sec) | ≤10.5 |
SERVICE REFILL CAPACITY
| Fuel Tank (L) | 350L |
| Hydraulic Tank (L) | 280L |
| Crankshaft (L) | 19L(CH-4) |
| Transmission (L) | 46L(CH-4) |
| Front Axle/Rear Axle (L) | 46/46L |
