CDM6060N Yanmar Ⅲ
Excavator
CDM6060N Yanmar Ⅲ
36.2 kW/2200 rpmRated Power
5850 kgOperating Weight
2.5/5.0 km/hTravel Speed
3.054 LDisplacement
Overview
The Lonking CDM6060N Yanmar Ⅲ is a excavator built for dependable, efficient operation. Powered by a 4TNV94L engine producing 36.2 kW/2200 rpm, with an operating weight of 5850 kg. Its robust drivetrain, precise hydraulics and operator-focused cab make it well suited to construction, mining, agriculture and industrial material-handling tasks.
Key Features
- 36.2 kW/2200 rpm engine output tuned for productive operation
- Ergonomic operator cab for comfort and visibility across long work shifts
- Supported by Lonking global genuine parts and after-sales service network
Technical Specifications
BASIC
| Operating weight | 5850 kg |
| Boom length | 3000 mm |
| Arm length | 1550 mm |
| Standard bucket | 0.25 m³ |
| Max.Travel speed | 2.5/5.0 km/h |
| Max.Swing speed | 11 rpm |
| Grade ability | 35°(70%) |
| Ground pressure | 31 kPa |
| Max.Traction force | 58.3 kN |
ENGINE
| Engine model | 4TNV94L |
| Rated power | 36.2 kW/2200 rpm |
| Max.Torque | 212/1260±100 N.m/rpm |
| Displacement | 3.054 L |
| Fuel tank | 130 L |
HYDRAULIC
| Max.Flow(total) | 151 L/min |
| Max.Working pressure | 24.5 MPa |
| Max.Pilot pressure | 3.7 Mpa |
| Max.Arm digging force | 28 kN(ISO) |
| Max.Bucket digging force | 40 kN(ISO) |
| Hydraulic oil tank | 80 L |
CHASSIS
| Track width | 400 mm |
| Track shoes number | 38(each side) |
| Carrier rollers number | 1(each side) |
| Track rollers number | 5(each side) |
ELECTRIC
| System voltage | 12 V |
| Battery capacity | 12 V,100 Ah |
